EPSON AcuLaser C9200N Revision D
OPERATING PRINCIPLES Operating Principle of Main Unit Mechanism 69
Confidential
2.2.12 Bypass section (MP tray)
2.2.12.1 Composition
Figure 2-54. Composition
4038T2C112AA
4039T2C114AA
MP tray Paper Empty Sensor (PC13)
Paper Side Plate
Paper Side Plate
4038T2C181AA
MP tray Feed Roller
(Bypass)
MP tray Paper Empty Sensor (PC13)Paper Lifting Plate
MP tray Separation Roller
