Epson Aculaser C9200N - Toner Collecting Section

EPSON AcuLaser C9200N Revision D
OPERATING PRINCIPLES Operating Principle of Main Unit Mechanism 63
Confidential
2.2.10 Toner Collecting section
2.2.10.1 Composition
Figure 2-44. Composition
4038T2C110AA
4039T2C11AA
4038T2C023DA
PU Toner Collecting Screw
Transfer Belt Toner Collecting Screw
Waste Toner Collector
4038T2C024DA
Waste Toner Full Sensor (PC8)
Waste Toner Conveyance Screw
Waste Toner Collector
