EPSON AcuLaser C9200N Revision D
Troubleshooting Service Call Error 113
Confidential
3.3.2 Solution to Engine-Related Error
E100: POLYGON MOTOR/C FAILURE TO TURN
E101: POLYGON MOTOR/M FAILURE TO TURN
E102: POLYGON MOTOR/Y FAILURE TO TURN
E103: POLYGON MOTOR/K FAILURE TO TURN
E110: LASER MALFUNCTION (CYAN)
E111: LASER MALFUNCTION (MAGENTA)
E112: LASER MALFUNCTION (YELLOW)
E113: LASER MALFUNCTION (BLACK)
Relevant Electrical Parts
 PH Unit
 PH Interface Board (PWB-D)
 Mechanical Control Board (PWB-M)
Step Action
Connection Diagram
Control Signal
Location
(electrical parts)
1 Check the connector for proper
connection and correct as necessary.
--- ---
2 Change PH Unit (p.175) --- ---
3 Change PWB-D (p.175) --- ---
4 Change PWB-M (p.198) --- ---
Relevant Electrical Parts
 PH Unit
 PH Interface Board (PWB-D)
 Mechanical Control Board (PWB-M)
Step Action
Connection Diagram
Control Signal
Location
(electrical parts)
1 Check the connector for proper
connection and correct as necessary.
--- ---
2 Change PH Unit (p.175) --- ---
3 Change PWB-D (p.175) --- ---
4 Change PWB-M (p.198) --- ---
