EPSON AcuLaser C9200N Revision D
OPERATING PRINCIPLES Operating Principle of Main Unit Mechanism 54
Confidential
2.2.9 Transfer Corona section
2.2.9.1 Composition
1ST IMAGE TRANSFER SECTION
Figure 2-31. Composition
4039T2C110AA
4038T2C105AA
4038T2C151AA
1st Image Transfer
Roller/Y
1st Image Transfer Roller/M
1st Image Transfer
Roller/C
1st Image Transfer Roller/K
2nd Transfer Roller
Retraction Roller
Cleaning Blade
Transfer Belt Drive Roller
4038T2C018DB
Pressure Cam
1st Image Transfer Pressure/
Retraction Clutch (CL3)
Fusing Motor (M4)
1st Image Transfer
Retraction Position
Sensor (PC6)
