Epson Aculaser C9200N - Reset Life Counter

EPSON AcuLaser C9200N Revision D
ADJUSTMENT Adjustment 317
Confidential
5.2.3 Reset Life Counter
PURPOSE
Whenever the parts (units) which record the life counter (consumption) in the printer
are replaced with new one, the life counter of corresponding the parts must be reset (set
to "0").
PROCEDURE
1. Assemble the printer completely.
2. Turn the printer on to keep on pressing [Left], [Up], [Down] and [Right].
3. After the printer has been activated and “MAINTENANCE MODE” is displayed
on the LCD panel, release the buttons which are being pressed.
4. Press [Up] or [Down] a few times to select “Maintenance Menu” and press [OK].
5. Press [Up] or [Down] a few times to select “Reset xxxxx Counter” and press [OK]
to reset the life counter.
Table 5-1. Reset Life Counter List
Unit Menu Name
Maintenance unit Reset Maint Counter
Feed Roller (C2) Reset LC2 Counter
Feed Roller (C3) Reset LC3 Counter
Feed Roller (C4) Reset LC4 Counter
