EPSON AcuLaser C9200N Revision D
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 170
Confidential
DISASSEMBLY FLOWCHART
A1
B1
C1
D1
E1
Start
2nd Transfer Unit
(P. 171)
Dust Filter
(P. 172)
Feed Roller (Std. Cassette)
(P. 172)
Ozone Filter
(P. 171)
Separation Roller (Std. Cassette)
(P. 173)
