EPSON AcuLaser C9200N Revision D
APPENDIX Control Panel Special Operations 350
Confidential
MAINTENANCE MENU
Setting item Settings Explanation
Maintenance
StatusSht
Execute Prints Maintenance Status Sheet and Error Log
Sheet.
Clear Error Log
Execute Clears the saved error log to print it on Error Log
Sheet.
K Toner Admix
Execute Supplies toner to the developing unit from the
toner cartridge forcibly. Execute this setting for
the low density.
C Toner Admix
Execute
M Toner Admix Execute
Y Toner Admix Execute
Reset Mainte Counter Execute Resets the life counter of the maintenance unit.
Execute this setting after replacing the
maintenance unit.
Reset LC2 Counter
Execute Resets the life counter of the feed roller (C2).
Execute this setting after replacing the feed
roller.
Reset LC3 Counter
Execute Resets the life counter of the feed roller (C3).
Execute this setting after replacing the feed
roller.
Reset LC4 Counter
Execute Resets the life counter of the feed roller (C4).
Execute this setting after replacing the feed
roller.
Feed Offset MP
-3.5 ~ 0.0 ~ 3.5 Sets margins for each paper feeder. “Feed”
indicates the margin on the leading edge of the
paper and “Scan” indicates the margin on the left
edge of the paper.
Scan Offset MP
-3.5 ~ 0.0 ~ 3.5
Feed Offset C1 -3.5 ~ 0.0 ~ 3.5
Scan Offset C1 -3.5 ~ 0.0 ~ 3.5
Feed Offset C2 -3.5 ~ 0.0 ~ 3.5
Scan Offset C2 -3.5 ~ 0.0 ~ 3.5
Feed Offset C3 -3.5 ~ 0.0 ~ 3.5
Scan Offset C3 -3.5 ~ 0.0 ~ 3.5
Feed Offset C4 -3.5 ~ 0.0 ~ 3.5
Scan Offset C4 -3.5 ~ 0.0 ~ 3.5
ScanOffset DupMP -3.5 ~ 0.0 ~ 3.5 Sets the margin on the left edge of the back of a
paper for each Paper Feeder.
ScanOffset DupC1
-3.5 ~ 0.0 ~ 3.5
ScanOffset DupC2 -3.5 ~ 0.0 ~ 3.5
ScanOffset DupC3 -3.5 ~ 0.0 ~ 3.5
ScanOffset DupC4 -3.5 ~ 0.0 ~ 3.5
C Regist Feed -6 ~ 6 Corrects printing positions for each color.
“Feed” indicates the vertical direction, and
“Scan” indicates the horizontal direction.
C Regist Scan
-6 ~ 6
M Regist Feed -6 ~ 6
M Regist Scan -6 ~ 6
Y Regist Feed -6 ~ 6
Y Regist Scan -6 ~ 6
Loop Fuser -2 ~ 2 Corrects the timing that the speed control of
fusing starts to prevent paper wrinkles that may
occur when printing envelopes.
Temp1 Normal
-10 ~ 10 Corrects the heater temperature of the fuser unit.
“1” indicates the heater of the heat roller, and
“2” indicates the heater of the press roller.
Temp2 Normal
-10 ~ 10
Temp1 Thick -10 ~ 10
Temp2 Thick -10 ~ 10
Temp1 ExtraThk -10 ~ 10
Temp2 ExtraThk -10 ~ 10
Temp1 SuperThk 0 ~ 10
Temp2 SuperThk 0 ~ 10
Temp1 Envelope -10 ~ 10
Temp2 Envelope -10 ~ 10
Temp1 Trnsprnc -10 ~ 10
Temp2 Trnsprnc -10 ~ 10
Transfer 1st NN -5 ~ 5 Sets the primary transfer bias in NN
environment. As the set value takes one step up/
down, the transfer bias changes per 50 V.
*NN environment = Environment that
temperature and humidity are in standard value.
Setting item Settings Explanation
