Transporting the Printer
If you need to transport your printer some distance, carefully
repack it using the original box and packing materials, as
described below:
1.
2.
3.
4.
5.
6.
7.
8.
Turn off the printer.
Unplug the power cord from the electrical outlet; then
disconnect the interface cable from the printer.
Remove the paper guide.
Remove the optional pull tractor, cut-sheet feeder, or roll-paper
holder if installed.
Remove the ribbon cartridge.
Remove the paper-tension unit. Attach the protective locking
clip to the paper-tension unit, and then replace the paper
tension unit.
Make sure the standard tractor is installed in the push tractor
position.
Repack the printer, ribbon cartridge, paper guide, and power
cord in the original packing materials and place them in the
printer’s original box.
5-4
Maintenance and Transportation
