Electrical
120V model:
Rated voltage:
Input voltage range:
Rated frequency range:
Input frequency range:
Rated current:
Power consumption:
Insulation resistance:
Dielectric strength:
AC 120 V
AC 103.5 to 132 V
50 to 60 Hz
49.5 to 60.5 Hz
l.0 A*
Approx. 69 W
(self test in draft mode, 10 cpi)
10 M min (between AC line and
chassis, DC 500 V)
AC 1000 Vrms. 1 min, or
AC 1200 Vrms. 1 sec.
(between AC line and chassis)
*Maximum 1.8 A depending on the character type.
230V model:
Rated voltage:
Input voltage range:
Rated frequency range:
Input frequency range:
Rated current:
Power consumption:
AC 220 to 240 V
AC 198 to 264 V
50 to 60 Hz
49.5 to 60.5 Hz
0.5
A*
Approx. 60 W (self test in draft mode, 10 cpi)
A-10
Specifications, Command Summary, and Character Tables
