4. Fan a stack of paper (up to 150 sheets); then tap the side and
bottom of the stack on a flat surface to even it up.
Caution:
Do not use labels in the cut-sheet feeder.
5.
Insert the paper along the left paper guide.
6.
Adjust the position of the right paper guide so that it matches
your paper’s width. Make sure the position of the guide allows
the paper to move up and down freely.
7.
Push back the paper-set levers to clamp the paper against the
guide rollers.
8. Lift up the center support and select single sheet or continuous
paper by moving the paper selection lever as shown below.
Note:
When the cut-sheet feeder is installed, you can still load single sheets
using the top paper guide or the front paper slot.
The cut-sheet feeder loads paper when you send data to the
printer (as long as the Pause light is not on). You can also load
paper by pressing the
Load/Eject
button.
Using Printer Options
4-5
