TROUBLESHOOTING Troubleshooting 29
Table 3-8. The Fluorescent Lamps does not light up (the Main Unit).
Step Cause Point to be checked Result Corrective Action
1
The Carriage FFC is
disconnected from the Main
Board.
Is the Carriage FFC
disconnected from the Main
Board?
Yes Connect the FFC.
2 The Carriage Unit failure. — Yes
Replace the Carriage Unit
with a new one. (Refer to
4.3.9 Carriage Unit P41)
3 Main Board failure. — Yes
Replace the Main Board with
a new one. (Refer to 4.3.6
Main Board P37)
Table 3-9. The Fluorescent Lamps does not light up (TPU).
Step Cause Point to be checked Result Corrective Action
1
The connector of the
Fluorescent Lamp is
disconnected from the TPU
Inverter Board.
Is the connector of the
Fluorescent Lamp
disconnected from the TPU
Inverter Board?
Yes Connect the connectors.
2
The TPU Inverter Board
failure.
— —
Replace the TPU Inverter
Board with a new one. (Refer
to 4.4.2 Harness TPU/TPU
Inverter Board P44)
3
Main Unit Main Board
failure.
——
Replace the Main Board with
a new one. (Refer to 4.3.6
Main Board P37)
Table 3-10. The films are not fed or ejected (AFL).
Step Cause Point to be checked Result Corrective Action
1
The connector of the AFL
Sensor A is disconnected
from the AFL Main Board.
Is the connector of the AFL
Sensor A disconnected from
the AFL Main Board?
Yes Connect the connectors.
2
The AFL Motor connector is
disconnected from the AFL
Main Board.
Is the AFL Motor connector
disconnected from the AFL
Main Board?
Yes Connect the connectors.
3
The connector of the AFL
Sensor B is disconnected from
the AFL Main Board.
Is the connector of the AFL
Sensor B disconnected from
the AFL Main Board?
Yes Connect the connectors.
4 The AFL Main Board failure. — —
Replace the AFL Main Board
with a new one. (Refer to
4.5.2 Harness AFL/AFL Main
Board P47)
5
Main Unit Main Board
failure.
——
Replace the Main Board with
a new one. (Refer to 4.3.6
Main Board P37)
Table 3-11. The Fluorescent Lamps does not light up (AFL).
Step Cause Point to be checked Result Corrective Action
1
The connector of the
Fluorescent Lamp is
disconnected from the AFL
Inverter Board.
Is the connector of the AFL
Fluorescent Lamp
disconnected from the AFL
Inverter Board?
Yes Connect the connectors.
2
The AFL Inverter Board and
the AFL Main Board are not
connected by the connector
cable.
The AFL Inverter Board and
the AFL Main Board are not
connected by the connector
cable?
Yes Connect the connectors.
3 The AFL Main Board failure. — —
Replace the AFL Main Board
with a new one. (Refer to
4.5.2 Harness AFL/AFL Main
Board P47)
4
The Main Unit Main Board
failure.
— —
Replace the Main Board with
a new one. (Refer to 4.3.6
Main Board P37)

Epson PERFECTION V10 Specifications

General

Color scanning	Yes
Input color depth	48 bit
Maximum scan size	216 x 297 mm
Optical density (Dmax)	3.2
Flatbed scan speed (b/w, A4)	34 sec/page
Scanner type	Flatbed scanner
Sensor type	CCD
Minimum RAM	128 MB
Minimum processor	Pentium II 450MHz
Minimum storage drive space	350 MB
Minimum system requirements	CD-ROM
Compatible operating systems	Windows 98SE/Me/2000/XP/XP 64-bit Mac OS X 10.2.8 +
USB version	2.0
Standard interfaces	USB 2.0
Compatibility	PC / Mac
Dimensions (WxDxH)	280 x 430 x 41 mm
Power requirements	100-240V; 50/60Hz
Bundled software	EPSON Scan & EPSON Creativity Suite ArcSoft PhotoImpression 5 ABBYY FineReader Sprint 6 ABBYY FineReader Sprint 5 (Mac)
Power consumption (standby)	3.5 W
Power consumption (typical)	16 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 80 %
Pallet width	800 mm
Pallet height	2150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	70 pc(s)
Quantity per pallet (UK)	100 pc(s)
Quantity per pallet layer	14 pc(s)
Quantity per pallet layer (UK)	20 pc(s)
Package depth	490 mm
Package width	105 mm
Package height	400 mm
Package weight	2975 g
Quantity per pack	1 pc(s)
Country of origin	Indonesia

Weight and Dimensions

Weight	2200 g
