101
A
Projector Installation
This appendix provides guidelines on installing the projector in a
permanent location, such as a theater or conference room.
Installation Guidelines
The projector can be installed for four different viewing setups: front
projection, ceiling projection, rear projection onto a semi-transparent
screen, or rear/ceiling projection, as shown:
To project from overhead, you’ll need the optional ceiling mounting
hardware (see page 9). You’ll also need to select the appropriate
Projection setting in the projector’s Extended menu to flip the image
upside-down (see page 67).
Front projection Rear projection
Rear/ceiling projectionCeiling projection
