80 Maintaining the Projector
3. Loosen the lamp cover screws (you don’t need to remove them).
Then remove the lamp cover.
4. Loosen the two screws holding the lamp in place (you can’t
remove them).
5. Hold the lamp as shown and pull it straight out.
6. Gently insert the new lamp. (If it doesn’t fit easily, make sure it is
facing the right way.)
note
Even when the lamp cover is
removed, it is still attached
to the projector to prevent it
from falling when the
projector is mounted on the
ceiling.
Loosen, but don’t
remove these screws
note
The lamp(s) in this
product contain mercury.
Please consult your state and
local regulations regarding
disposal or recycling. Do not
put in the trash.
