Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
ADJUSTMENT Overview 263
SE Group Confidential (Related Staff Only)
Head related
parts/units
Print Head
After
replacement
11 Turn the power on in Serviceman mode. ---
√
---
12 Reset the Print Head Counter.
√√
--- p. 293
13 Head ID Input
√√
--- p.309
14 Turn the power off. ---
√
---
15 Turn the power on in normal mode. ---
√√
16 Setting [0 RIP Settings] ---
√√
p. 148
17 Load the media. --- PGPP
√√
18 Cleaning (CL3 twice + CL1 once)
√√√
p. 313
19 Nozzle Check
√
PGPP
√√
p. 311
20 Head inclination manual adjustment (CR direction)
√
PGPP
√√
p. 314
21 Ink Mark Sensor Check & Auto Adjustment
√ PGPP √
--- p. 303
22 Head slant auto adjustment (PF direction)
√
PGPP
√√
p.319
23 Turn the power off. ---
√√
24 PG Adjustment --- Thickness gauge
√√
p.306
25 Turn the power on in normal mode. ---
√√
26 Manual Adjustment for Data Shift
√
PGPP
√√
p. 321
27 Manual Uni-d Adjustment for Between 2pcs heads
√
PGPP
√√
p.323
28 Manual Uni-d adjustment
√
PGPP
√√
p.325
29 Manual Bi-d adjustment
√
PGPP
√√
p.327
30 Activate the ink tanks.
√√√
p. 329
31 Turn the power off. ---
√√
32 Remove the ink cartridges for service. ---
√√
p. 207
33 Install the ink tanks. ---
√√
p. 207
34 Turn the power on in normal mode. ---
√√
35 Make sure the error never recurs. ---
√√
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
