Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
ADJUSTMENT Overview 266
SE Group Confidential (Related Staff Only)
Ink supply
related parts/
units
Ink Tube
Before
replacement
1 Turn the power on in Serviceman mode. ---
√√
2 Reset the tube counter.
√√
--- p. 293
3 Turn the power off. ---
√√
4 Turn the power on in normal mode. ---
√√
5 Dispose of waste ink. ---
√√
6 Reset the waste ink counter. √
√√
p. 293
7
Activate the ink cartridges for service.
√√√
p. 329
8 Turn the power off. ---
√√
9 Remove the ink tanks. ---
√√
p. 207
10 Lower the lock levers. ---
√√
11 Turn the power on in Serviceman mode. ---
√√
12 Reset the waste ink bottle counter. ---
√√
13 Ink eject
√√√
p. 332
Replacement
14 Auto CR unlock & move CR to full column side
√ √ √
15 Replacement ---
√ √
p. 196
After
replacement
16 Install the ink cartridges for service. ---
√√
p. 207
17 Turn the power on in normal mode. ---
√√
18 Dispose of waste ink. ---
√√
19 Reset the waste ink counter. √
√√
p. 293
20 Initial ink charge
√√√
p. 334
21 Nozzle Check
√
PGPP
√√
p.311
22 Cleaning (CL1 or CL2)
√√√
p.313
23 Activate the ink tanks.
√√√
p. 329
24 Turn the power off. ---
√√
25 Remove the ink cartridges for service. ---
√√
p. 207
26 Install the ink tanks. ---
√√
p. 207
27 Turn the power on in normal mode. ---
√√
28 Make sure the error never recurs. ---
√√
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired
(Reattached) Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
