Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Parts Diagram 89
SE Group Confidential (Related Staff Only)
Figure 3-10. Roll Unit
 Roll Unit (p. 236)
 Roll Receiver Assy (p. 237)
 Roll Paper Holder (p. 238)
 Sub-F Board (Roll) (p. 239)
Relays the connection between the Main Board and the Roll
Unit. See “6.1 Block Wiring Diagram (p390)” for specific
connections to the concerning parts/components.
 ATC Motor (p. 241)
Feeds forward (normal rotation) and rewinds (reverse
rotation) the roll paper to generate back tension.
* ATC: Auto Tension Control
