ADJUSTMENT Adjustment Items and Overview (T.B.D) 104
EJ Roller
Removal -- -- -- -- -- -- -- Required Required Required --
Replacement -- -- -- -- -- -- -- Required Required -- --
PF Roller
Removal -- -- -- -- -- Required Required Required Required Required --
Replacement -- -- -- -- -- Required Required Required Required Required --
PF Motor
Removal -- -- -- -- -- Required Required Required Required Required --
Replacement -- -- -- -- -- Required Required Required Required Required --
Power Supply Board
Removal -- -- -- -- -- -- -- -- -- -- --
Replacement -- -- -- -- -- -- -- -- -- -- Required
EJ Frame Assy
Removal -- -- -- -- -- Required -- Required Required Required --
Replacement -- -- -- -- -- Required -- Required Required Required --
Table 5-4. Adjustment Items
Priority 1 2 3 4 5 6 7 8 9 10 11
EEPROM
data copy
Initial
setting
Waste ink
pad counter
Ink charge
Head ID
input
TOP margin
adjustment
First dot
adjustment
Head
Angular
adjustment
Bi-D
adjustment
PF band
adjustment
CR heat
protection
control
Adjustment item
Replaced parts
