EPSON Stylus CX4300/CX4400/CX5500/CX5600/DX4400/DX4450 Revision A
OPERATING PRINCIPLES Printer Mechanism 27
2.2.4 Ink System Mechanism
The Ink system mechanism consists of pump mechanism and capping mechanism that
includes wiper mechanism.
2.2.4.1 Pump Unit Mechanism
When the PF motor turns, power is always transmitted to the ink system.
Note * : The PF Motor rotational direction = seen from the left side of the printer.
2.2.4.2 Capping Mechanism
The Capping mechanism covers the printhead with the cap to prevent the nozzle from
increasing viscosity when the printer is in stand-by state or when the printer is off.
Table 2-3. PF Motor Rotational Direction & Ink System Mechanism
Direction* Function
Counterclockwise Absorbs the ink by the Pump Unit
Clockwise Release pump.

Epson Stylus CX4300 Specifications

General

Technology	Inkjet
Functions	Print, Scan, Copy
Print Resolution (Black)	5760 x 1440 dpi
Print Resolution (Color)	5760 x 1440 dpi
Scanner Type	Flatbed
Scan Resolution	600 x 1200 dpi
Copy Speed (Color)	9 cpm
Connectivity	USB
Operating Systems	Windows, Mac
Printer Type	All-in-One
Paper Sizes	A4, A5, B5, Letter, Legal, Envelopes
Ink Cartridges	4 (Black, Cyan, Magenta, Yellow)
