EPSON Stylus CX4300/CX4400/CX5500/CX5600/DX4400/DX4450 Revision A
ADJUSTMENT Adjustment Items and Overview (T.B.D) 103
5.1.2 Replacement Part Adjustment Items (T.B.D)
The following table indicates the adjustment items for replacement parts.
Note: “Required” in this table indicates the adjustment item that must be executed when the corresponding part has been removed/replaced. “Required” indicates the adjustment item that must be
executed since the part is related to the corresponding part to be removed/replaced, or the adjustment item that must be executed when the corresponding part has been removed/replaced. “-” indicates
that no adjustment is required. When you have removed/replaced two or more parts, refer to the corresponding items of all parts. Also, if there are several adjustment items for one exchanging part,
execute the adjustment in the priority order mentioned in the table.
Table 5-4. Adjustment Items
Priority 1 2 3 4 5 6 7 8 9 10 11
EEPROM
data copy
Initial
setting
Waste ink
pad counter
Ink charge
Head ID
input
TOP margin
adjustment
First dot
adjustment
Head
Angular
adjustment
Bi-D
adjustment
PF band
adjustment
CR heat
protection
control
Hopper
Removal -- -- -- -- -- Required -- -- -- Required --
Replacement
-- -- -- -- -- Required -- -- -- Required --
Main Frame
Removal -- -- -- -- -- Required Required Required Required Required --
Replacement -- -- -- -- -- Required Required Required Required Required Required
Main Board
Removal -- -- -- -- -- -- -- -- -- -- --
Replacement Required -- -- -- -- -- -- -- -- -- --
Replacement
(EEPROM Copy NG)
-- Required
Ink Pads
must be
replaced
-- Required Required Required Required Required Required Required
LD roller/ASF unit
Removal -- -- -- -- -- Required -- Required Required Required --
Replacement -- -- -- -- -- Required -- Required Required Required Required
Wasted ink Pads
Removal -- -- -- Required -- Required -- Required Required Required --
Replacement -- -- Required Required -- Required -- Required Required Required --
Printhead
Removal -- -- -- -- -- Required Required Required Required Required --
Replacement -- -- -- Required Required Required Required Required Required Required --
CR Motor
Removal -- -- -- -- -- -- Required Required Required -- --
Replacement -- -- -- -- -- -- Required Required Required -- Required
CR unit/Timing Belt
Removal -- -- -- -- -- Required Required Required Required Required --
Replacement -- -- -- -- -- Required Required Required Required Required Required
Ink System (Pump)
Removal -- -- -- Required -- Required Required Required Required Required --
Replacement -- -- -- Required -- Required Required Required Required Required --
Adjustment item
Replaced parts

Epson Stylus CX4300 Specifications

General

Technology	Inkjet
Functions	Print, Scan, Copy
Print Resolution (Black)	5760 x 1440 dpi
Print Resolution (Color)	5760 x 1440 dpi
Scanner Type	Flatbed
Scan Resolution	600 x 1200 dpi
Copy Speed (Color)	9 cpm
Connectivity	USB
Operating Systems	Windows, Mac
Printer Type	All-in-One
Paper Sizes	A4, A5, B5, Letter, Legal, Envelopes
Ink Cartridges	4 (Black, Cyan, Magenta, Yellow)
