Chapter 2 Setup
2
Connecting the Drawer Kick Cable
Connect the drawer kick cable to the drawer kick connector by pressing firmly until the connector clicks
into place.
WARNING
• Use a shield cable for the drawer kick cable.
• When using cash drawer, make sure to use the power supply for printer (connector
pins 4).
• Do not insert a telephone line into the drawer kick connector.
• Doing so may damage the telephone line or printer.
