Printable Area
The print area may be out of alignment by 2 mm {0.08”} maximum to the left or right. When setting the
print area, refer to the table and figure below to allow enough margins to the left and right.
Units: mm
80 mm width paper
58 mm width paper
Paper width
(mm)
80 70 65 60 58 50 45 38
Printable area 72 {2.83”} 64 {2.52”} 59 {2.32”} 54 {2.13”} 52 {2.05”} 44 {1.73”} 39 {1.54”} 32 {1.26”}
Left margin 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”} 2.65 {0.10”}
Right margin 4.85 {0.19”} 2.85 {0.11”} 2.85 {0.11”} 2.85 {0.11”} 2.85 {0.11”} 2.85 {0.11”} 2.85 {0.11”} 2.85 {0.11”}
Total number of
dots
576 512 472 432 416 352 312 256
79.5 ± 0.5 mm {3.13 ± 0.02”}
0.125 mm {0.005”}
72 mm {2.83”}
576 dots
(2.65 mm {0.10”} ) (4.85 mm {0.19”})
0.125 mm
{0.005”}
420 dots
52.5 mm {2.07”}
(2.65 mm (4.85 mm
{0.10”} ) {0.09”})
57.5 ± 0.5 mm {2.26 ± 0.02”}
