47
Chapter 2 Setup
2
4
Pass each cable through the cable exits at the bottom of the connector
cover.
If the cables are too many for one cable exit, use multiple exits.
5
Turn over the product and make sure the cables are not pinched.
To remove the connector cover, turn the product over, and push the connector cover down while
pushing both sides of the connector cover inward to detach the hooks form the printer case.
