Epson TM-U220-i Technical Reference Guide

33
Chapter 2 Setup
2
4
Rotate the detector lever on the roll paper guide to change its direction.
After the directi on of the detector lever is changed, be sure t hat the cable is connected to the
connector firmly.
5
Tighten the detector adjustment screw.
Detector lever
Cable
Detector adjustment screw

Epson TM-U220-i Specifications

General

Type	POS printer
Color	Yes
Print technology	Dot matrix
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximum roll diameter	83 mm
Standard interfaces	Ethernet, Parallel, RS-232, RS-485, USB, Wireless LAN
Serial interface type	RS-232, RS-485
Connectivity technology	Wired & Wireless
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking, AS/NZS 3548 class B
Mean cycles between failures (MCBF)	18000000
Safety	UL, CSA, TÜV (EN60950)
Mean time between failures (MTBF)	180000 h
Product color	Gray

Weight and Dimensions

Depth	248 mm
Width	160 mm
Height	138.5 mm
