Getting to Know Your Product
Product Parts
Note:
The illustrations in this section are from a similar product model. Although they may differ from your actual product, the
method of operation is the same.
a. ADF cover *
b. Automatic Document Feeder (ADF) *
c. Edge guide *
d. ADF input tray (place your originals here to be copied) *
e. ADF output tray (your originals are ejected here as they are copied) *
f. Paper cassette 1
g. Paper cassette 2 (optional)
* These parts are only available for the fax model.
