3.1.1 INDICATORS
AL 1 - AL 2
Indicator OFF = no alarm condition
Indicator ON = alarm condition
PK H
Indicator OFF = instrument shows the measured value
Indicator ON = instrument shows the "Peak high" value
PK L
Indicator OFF = instrument shows the measured value
Indicator ON = instrument shows "Peak low" value
LOCK
Indicator OFF = alarms threshold protection disabled
Indicator ON = alarms threshold protection enabled
REM
Indicator OFF = setting by serial communication interface
disabled
indicator ON = setting by serial communication interface
enabled
3.1.2 DISPLAYS
NUMERICAL DISPLAY
The numerical display shows continuously the process variable in
eng. units.
During configuration and calibration set up, this display is used, in
addition to the alphanumerical display, to show the parameters
name and the relative value.
ALPHANUMERICAL DISPLAY
The alphanumerical display normally shows the engineering unit of
the displayed value.
During configuration and calibration set up, this display is used, in
addition to the numerical display, to show the parameters name
and the relative value.
