ero electronic DPS - Linear Input; RTD (Resistance Temperature Detector)

7
B) Linear input
Input type: See table below
Readout: keyboard programmable between -1999 and +9999.
Linearization: input signal may be linearized by setting up to 9
breakpoints (10 segments) on the input span.
Square root estraction: programmable
Decimal point : programmable in any position.
Burn out: Up scale for 12-60 mV inputs;
down scale for 4-20 mA, 1-5 V and 2-10 V.
It is not detectable for the other ranges.
STANDARD RANGES TABLE
C) RTD (Resistance Temperature Detector)
Input: for RTD Pt100 Ω and Ni 100 Ω, 3 wire connection with °C/°F
selectable by front pushbuttons.
Input circuit: current injection (100 µA).
Line resistance: automatic compensation up to 3 Ω/wire with no
measurable error.
Calibration: according to DIN 43760
Standard ranges: see table
Burn out: up scale or down scale programmable for open circuit of one
or more wires.
STANDARD RANGES TABLE
Input
type
- 199.9 / + 850.0 °C
- 60.0 / + 350.0 °C
- 328 / + 1560 °F
- 76 / + 660 °F
Ranges
RTD Pt 100
ΩΩ
ΩΩ
Ω
RTD Ni 100
ΩΩ
ΩΩ
Ω
Input
type
0 - 20 mA
4 - 20 mA
0 - 60 mV
12 - 60 mV
0 - 5 V
1 - 5 V
0 - 10 V
2 - 10 V
Accuracy
Input inpedance
3 Ω
3 Ω
> 800 kΩ
> 800 kΩ
> 200 kΩ
> 200 kΩ
> 200 kΩ
> 200 kΩ
0.1 % + 1 digit
@ 25°C
