SECTION 1 GENERAL INFORMATION
1.1 INTRODUCTION
The DPS is a family of digital panel indicators developed with a
variety of features for the solution of field problems.
As part of ERO ELECTRONIC background, this family also
maintains a high standard in quality, reliability and man/machine
interface simplicity, but it encompasses performance typically built
in very expensive instruments.
Features like frequency input, switching power supply, square root
extraction on the input variable, linearization by keyboard with the
setting of 9 breakpoints (10 segments), max. value data hold, min.
value data hold and analog retransmission of the displayed value
offer the widest range of possible application.
The two color custom integrated display with 4 numerical digit, 2
alphanumerical characters and 6 indicators, is an example of the
particular attention given to the design of the man/machine
interface.
The DPS comes with a complete availability of ranges from thermo-
couple, RTD and mA, digital filter, two logic inputs, two independent
alarms and it can be also supplied with serial communication interface
and a galvanically isolated auxiliary power supply.
1.2 PRODUCT SPECIFICATIONS
1.21 GENERAL SPECIFICATIONS
Case : PC/ABS black color; self-extinguishing degree : V-0
according to UL.
Front panel : IP 54 protection (IEC 529 and CEI 70-1).
Installation :panel mounting by means of tie rods.
Instrument removable from case by screwdriver help
Plug in construction :PC boards are assembled by snap in action
for easy inspection and replacement of all boards.
Rear terminal block: with screw terminals and completed with
identification labels, connection diagrams and safety rear cover.
Dimensions: DIN 43700 48 x 96 mm, depth 149 mm.
Cut-out : 45 x 92 mm +0,8 mm - 0,0 mm.
Weight : 600 g max.
Displays: LCD with high brightness solid state back lighter
numerical display: 4 digits, 7 segments with decimal point,
14.5 mm high, from -1999 to 9999.
alphanumerical display:2 digits, 16 segments with
decimal point, 9 mm high,
Front indicators: AL1- AL2- PK H- PK L- LOCK- REM.
Power supply: 100V to 240V AC 50/60Hz (-15% to +10% of the
nominal value).or 24 V AC/D.C (
+10% of the nominal value).
Power consumption : 8 VA max.
Insulation resistance: > 100 MΩ according to IEC 348.
Dielectric strength: 1500 V in accordance with IEC 348.
