SECTION 6 DEFAULT PARAMETERS SETTING
6.1 PRELIMINARY
The instrument is delivered with a default parameters sets stored and
usable, in every moment, for clear all the memories.
Different parameters sets are provided for configuration, calibration
and operative modes but the memorization follows the same
procedure.
During every particular working mode it is possible to load only the
paramerets of the specific mode.
6.2 DEFAULT PARAMETERS SETTING
Push ▲ pushbutton and, maintaining the pressure, push ▼ pushbut-
ton.
The display will show "OFF" and "dF".
Pushing ▲ pushbutton, on the display will appear "ON".
Push F pushbutton to start default parameters loading.
During this routine the display will show "LOAD" and "dF".
After loading routine the instrument will return to the initial status.
6.3 DEFAULT CONFIGURATION PARAMETERS
1 Power supply frequency 50 Hz
2 Input type TC
3 TC type K
3.a RTD type Pt 100 Ω
3.b Engineering unit °C
3.c Burn-out Over range
4 Linear input type 4-20 mA
4.a Square root extraction Disabled
4.b Decimal point position None
4.c Initial scale readout -1999
4.d Final scale readout 9999
4.e Engineering unit °C
4.f Break points number 0
4.g Break points inputs with 10% step
4.h Break points readouts with 10% step
5 Readout digital filter 0.4 s
6 NOT USED
7 External contact function HOLD
7.a Contact status Closed
8 Options None
9 Analog retransmission type 4-20 mA
