3.1.3 KEYBOARD DESCRIPTION
To increase the parameter value or
select peak high visualization
To decrease the parameter value or
select peak low visualization
To select all the parameters .
Pushing the F pushbutton the parameters will be
shown sequentially on the displays and, at the
same time, the value of the previous parameter will
be stored.
During configuration and calibration procedures
and alarm threshold setting it is used to scroll back
the parameters without memorization of the new
values.
R
F
Alarm 1 manual reset
Alarm 2 manual reset
They are used to reset peak high
and peak low and restart the peak
detection procedure.
They are used to start the default
parameters loading procedure.
R
+
R
+
R
+
F
+
