32
3) TC TYPE
The display will show " tc " followed by:
K = NiCr/NiAl TC (IEC 584-1)
J = Fe/CuNi TC (IEC 584-1)
Jd = Fe/CuNi TC (DIN 43710 - 1977)
E = NiCr/CuNi TC (IEC 584-1)
T = Cu/CuNi TC (IEC 584-1)
Td = Cu/CuNi TC (DIN 43710 - 1977)
S = Pt10%Rh/Pt TC (IEC 584-1)
R = Pt13%Rh/Pt TC (IEC 584-1)
B = Pt30%Rh/Pt6%Rh TC (IEC 584-1)
W = W/W26%Re TC
W3 = W3%Re/W25%Re TC (STM - E 988 / 84)
W5 = W5%Re/W26%Re TC (STM - E 988 / 84)
N = Nicrosil/Nisil TC (IEC 584-1)
NM = Ni/Ni18%Mo TC (G.E. Co.)
PL = Platinel II (GHOST)
Push ▲ or ▼ pushbuttons to set the desired TC type.
Push the F pushbutton to memorize the new choice and go to the
parameter 3b.
3.a) RTD TYPE
The display will show "rtd " followed by:
PT = PT 100 Ω
NI = Ni 100 Ω
Push ▲ or ▼ pushbuttons to set the desired RTD type.
Push the F pushbutton to memorize the new choice and go to the
next parameter.
3.b) ENGINEERING UNIT
The display will show "En.Un" followed by:
°F = Fahrenheit degree
°C = Celsius degree
Push ▲ or ▼ pushbuttons to set the desired unit.
Push the F pushbutton to memorize the new choice and go to the
next parameter.
3.c) BURN OUT
The display will show "FL.SF" followed by:
Hi = when a burn out condition will be detected, the display
will show "OPEN", peak detection, analog retransmis-
sion and alarms work as an over range condition.
Lo = when a burn out condition will be detected, the display
will show "OPEN"; peak detection, analog retransmis-
sion and alarms work as an under range condition.
Push ▲ or ▼ pushbuttons to set the desired condition.
Push the F pushbutton to memorize the new choice and go to the
parameter 5.
