8) OPTIONS
The display will show "OPtn" followed by:
0 = no option provided (go to step 15)
1 = 2 alarms (go to step 11)
2 = 2 alarms plus serial interface (go to step 10)
3 = 2 alarms plus analog retransmission (go to step 9)
Push ▲ or ▼ pushbuttons and set the desired options.
Push the F pushbutton to memorize the new configuration and go
to the next parameter.
9) ANALOG RETRANSMISSION TYPE
The display will show "out" preceded by:
0 - 20 = output 0 - 20 mA
4 - 20 = output 4 - 20 mA
0 - 10 = output 0 - 10 V
Push ▲ or ▼ pushbuttons and set the desired output.
Push the F pushbutton to memorize the new set and go to the next
parameter.
NOTE: If the transfer from mA to V or vice versa is desired, it is
necessary to recalibrate the instrument as detailed in para. 5.3.
9.a) RETRANSMISSION MINIMUM SCALE VALUE
The display will show "LR" preceded by a number between -1999
and 9999.
The decimal point is positioned as programmed at step 4b or 6a.
No decimal point is provided for TC or RTD inputs.
Push ▲ or ▼ pushbuttons and set the desired value. Push the F
pushbutton to memorize the new value and go to the next param-
eter.
9.b) RETRANSMISSION MAXIMUM SCALE VALUE
The display will show "HR" preceded by a number between -1999
and 9999. Push ▲ or ▼ pushbuttons and set the desired value.
Push the F pushbutton to memorize the new value and go to the
next parameter.
9.c) DIGITAL FILTER ON THE ANALOG RETRANSMISSION
The display will show "FILt" followed by a number.
Using ▲ and ▼ pushbutton it is possible to select the same time
constant selected for readout or the exclusion of the filter (0
setting).
Push the F pushbutton to memorize the new value and go to the
parameter 11.
