28
3.2.1 PRELIMINARY HARDWARE SETTINGS
Before reassembling the instrument, make sure that all the
necessary hardware settings are made as detailed below:
For the input selection, the dip switches
V2 must be setted as follows
dip
1
OFF
OFF
ON
dip
2
OFF
OFF
ON
dip
3
OFF
ON
OFF
dip
4
OFF
ON
OFF
V2
OUT
V
mA/TC/mV
RTD
