Fig. 1.1 INSTRUMENT IDENTIFICATION LABEL
1.5 LABELS
1.5.1 IDENTIFICATION LABEL
The instrument identification label , see Fig. 1.1, is located externally
on the top rear of the housing.
It contains the following information:
a) The instrument Model Number on the left side column.
The model number includes the instrument code which allows the
instrument functions to be determined. Each code item contains a
brief description. A complete description of all the code items can
be found in chapter 1.5.
b) The instrument Serial Number on the bottom line.
1.5.2 ABRIDGED LABELS
Two abridged labels are provided to allow the instrument parts to be
identified.
They are located : (a) on the bottom of the card and display plastic
support; (b) internally on the bottom front of the housing.
The abridged labels contain the Model Number and the Serial Number
only.
MADE IN ITALY
MODEL
DPS
3
9
STATUS: XX XX
POWER SUPPLY: 100/240 V AC
INPUT : TC - RTD - MV - MA -V
XXXXX
SERIAL NUMBER: XX.XX.XXX
1 2 ALARMS
3
RS 485 + AUXILIARY POWER SUPPLY
1
