41
4.2.2 MANUAL RESET OF THE ALARMS
If the alarm has been configured as a latched alarm, the alarm status
( "ALx" indicator lit and relay deenergized) persists also after the
alarm condition disappears.
Pushing R and ▲ pushbuttons contemporarily it is possible to reset
the alarm 1 status.
Pushing R and ▼ pushbuttons contemporarily it is possible to reset
the alarm 2 status.
When the remote alarm reset is programmed (see section 3 step 7) it
will be possible to reset both alarms by an external contact.
The alarm reset action will be successful if the alarm condition has
disappeared only.
4.2.3 ALARMS THRESHOLD SETTING
The visualization of the alarms threshold is always possible while its
modification must be done in accordance to the programmed safety
lock.
Different situations may occur:
A) The LOCK indicator is lit. Proceed as follows:
A.1) Push the F pushbutton. The display show "A1" preceded by
alarm 1 threshold value.
In this case, the alarm threshold can't be modified unless a
modification of the safety lock value is made in configuration
procedure.
A.2) Push the F pushbutton. The alphanumerical display will show
"KY" preceded by four lines.
Push ▲ or ▼ pushbuttons and set the safety key value.
Pushing the F pushbutton the LOCK indicator goes OFF and
the display will show "A1" preceded by alarm 1 threshold
value.
Proceed as detailed in step B).
B) The LOCK indicator is OFF. Proceed as follow:
B.1) Push the F pushbutton. The alphanumerical display will show
"KY" preceded by four lines.
Go to step B.2.
