ESAB DTG 405 - Two Stroke Lift Arc DC; Two Stroke Hf-Ignition DC

- 60 -
4 TWO STROKE LIFT ARC DC
5 TWO STROKE HF-IGNITION DC
a: I1=10 % Imax=40 A b: slope1=20 % c: I2=100 A
d: slope2=50 % e: I3=10 % I2=10 A i: lift arc ignition
p: pressing torch button
a: I1=10 % Imax=40 A b: slope1=20 % c: I2=100 A
d: slope2=50 % e: I3=10 % I2=1 0A p: pressing torch button
2ladc.pcx
2hfdc.pcx
