ESAB DTG 405 - SPARE PARTS LIST

- 82 -
SPARE PARTS LIST
Item Qty Order-Nr. Denomination C
101 1 0469 868 001 Handle
102 1 0469 704 001 Front panel (Top)
103 1 0469 703 003 Front grill
104 1 0457 150 001 Side panel (left)
105 1 0458 165 052 Switch 0/1 32A Q1
106 1 0365 803 008 Quick connector red
107 1 0365 803 009 Quick connector blue
108 2 0458 165 065 Current terminal 1-pole X3, X7
109 1 0538 500 902 2 pole panel socket X5
110 1 0457 377 039 Gas connection nipple
111 1 0458 165 055 Remote regulator socket, Burndy, complete X4
112 1 0458 165 065 Current terminal 1-pole X2
113 2 0458 165 008 Castor wheel
114 2 0458 165 009 Sticker "Aristotig 405 AC/DC"
115 2 0457 377 022 Sticker "ESAB"
116 1 0457 149 001 Side panel (right)
117 1 0458 165 101 Cover
118 4 0455 174 002 Seal 20/5
119 1 0468 401 001 Sticker "10°"
121 1 0456 167 002 cover 39/31
