Escea DF960 - Page 15

B
ACDEFGSERVICE
15
B8 Fascia Dimensions
The dimensions of the fascias are shown below.
Edge Fascia
Slim Fascia & Stretch Fascia
A
T
C D
B
I
E
G
H
F
B9 Distance from Fireplace to Fascia Base
The installation requires a spacer below the appliance to allow room for the fascia to sit flush with the
non combustible floor or a hearth.
The following side-on view shows the measurement from the base of the fireplace to the base of the
fascia:
Spacer
55mm
Edge Fascia
Spacer
30mm
Slim Fascia &
Stretch Fascia
28
Slim Fascia &
Stretch Fascia
Fire
Base
52
Edge Fascia
Fire
Base
28
Slim Fascia &
Stretch Fascia
Fire
Base
52
Edge Fascia
Fire
Base
