C5 Installing the Horizontal Power Flue
NOTE: The appliance is designed only to operate using
the approved flexible or PolyPro flue supplied by Escea.
Other brands of flue may not fit, and this will aect the
appliance warranty.
The Horizontal Power Flue Wall Terminal must
be installed in the correct orientation (the small
horizontal slot should be at the bottom). This allows
for the correct operation of the flue system and
prevents the ingress of water.
The Horizontal Power Flue Wall Terminal must be
weather tight when installation is complete to prevent
damage to the dwelling. It must be installed by a
suitably qualified person.
Fit the Horizontal Power Flue Wall Terminal into the
hole and fix in place, making sure the installation is sealed appropriately to prevent the ingress of water
from outside the wall cladding. Take notice of the label on the termination which shows the correct
orientation of the terminal.
NOTE: It is the responsibility of the installer to ensure the Horizontal Power Flue Wall Terminal is installed
to all relevant building codes to ensure weather tightness.
