DF960 PRODUCT SPECIFICATION
MODEL NAME DF960
Description of Appliance Powerflued Gas Fire Heater
Star Rating 4.4-4.9 Stars
Max. Heat Output
7.7kW
A/NZ Approval No. AS/NZS 5263.1.3
Gas Type Natural Propane ULPG
Gas input
High 31 MJ/hr 31 MJ/hr 28 MJ/hr
Low 15 MJ/hr 14 MJ/hr 12 MJ/hr
Inlet Pressure
Max 5.0 kPa 5.0 kPa 5.0 kPa
Min 1.13 kPa 2.75 kPa 2.75 kPa
Operating Pressure on High 1.0 kPa 2.30 kPa 2.30 kPa
Operating Pressure @ Front Burner Jet on High 0.94 kPa 2.20 kPa 2.20kPa
Burner Jet Size
Front: 1.85mm
Rear: 1.70mm
Front: 1.20mm
Rear: 1.05mm
Front: 1.10mm
Rear: 1.02mm
Aeration Collar Hole Size for Logs & Embers/
Flakes
1 holes @ Ø4mm No Collars No Collars
Aeration Collar Hole Size for Coals 1 hole @ Ø2.5mm No Collars No Collars
Pilot injector #42 #27 #27
Appliance Dimensions (mm)
Width 943.0 mm
Height 596.0 mm
Depth 402.0 mm
Weight Kg 70 kg
Ignition System
Electronic Ignition to pilot system
Escea PCB
Ignition Activation 7 secs (approx)
Flame Safeguard Flame Rectification
Consumption 84W @ 0.35A 230V
Remote controls Yes
Timers Yes
Clock Yes
Function lock / child Yes
Temperature control Yes
Connections
Electric 230V AC
Gas 1/2" BSPP female lower right of fireplace chassis
Flue Type 4” and 3” Flexi Flue
Spigot
Location
Rear and centre
Data badge location On Chassis Base
