Take noce of the label on the terminaon which shows the correct orientaon of the terminal.
Creang the Hole in the Outside Wall
When cung the hole in the outside wall, be mindful of how the installaon of the horizontal powerue wall
terminal will be nished; the installaon must be weatherproof.
Ideal Hole/Cavity Size for Horizontal Powerue
Without Side Brackets With Side Brackets
X 298 mm 360 mm
Y 298 mm 298 mm
Z 175 mm (Excluding allowance for ue which exits here)
The horizontal powerue wall terminal can be aached to the wall in two ways:
A) From the front of the terminal:
B) By aaching the oponal wall terminal installaon brackets to the sides of the cavity and aaching the
horizontal powerue wall terminal to these, from the front:
A
B
