630791 DS MKII INSTALLATION MANUAL
WARNING!
THE REGULATOR THAT IS SUPPLIED WITH THE FIRE MUST NOT BE REMOVED. REMOVAL OF THE REGULATOR,
OR REPLACING IT WITH ONE NOT INTENDED FOR USE WITH AN ESCEA FIRE, WILL VOID THE LIMITED
APPLIANCE WARRANTY AND MAY BE DANGEROUS.
WARNING!

CARE WORKING CLOSE TO THE OPEN FLAME OF THE BURNERS.
The gas valve (see image) has manometer test points at A and B. Test
point A is used to measure the operang pressure - post-regulator
and test point B is used to measure the operang pressure on high
and low. (see secon "Gas Pressure Table - DS Series" on page 30 .
Turn the gas and power supplies ON.
Turn on the re by pressing the ‘ ’ buon on the remote. Within a
few seconds the appliance will begin its startup sequence with a 30
second purge of the ue fan. Aer the purge it will aempt ignion.
It may take several aempts to light the rst me due to air in the gas
line.
Once the re has lit the pilot and main burner you will be able to measure the operang pressure. Set the
remote thermostat temperature to 38°C by pressing ‘ ’ on the remote touch screen and ensure the remote is
kept in a cool environment. This will allow maximum gas ow into the appliance.
Ensure all other gas appliances within the house are sll able to operate at maximum.
Open test point A and aach a manometer tube to measure the operang pressure—post regulator.
If the operang pressure does not read within 5% of the table, remove the cap from the regulator (shaded grey
in image below) and adjust the threaded spring stop. Press the ‘ ’ buon again to shut down the re.
Once the operang pressure—post regulator—is set, remove the manometer tube from test point A. Be sure to
close test point A. Open test point B and aach a manometer tube in preparaon for measuring the operang
pressure on high and low. This will be done together with changing the operang pressure from the APP (see
next page).
NOTE: It is also possible to measure the operang pressure on high and low by aaching a manometer
to one of the side burner jets. The measured pressure at the jet is generally slightly lower than at the test
point. If this is done, TAKE CARE to have the middle and other side burner installed, otherwise gas may
collect in the rebox, creang unsafe condions.
A
B
