F
50
630791 DS MKII INSTALLATION MANUAL
(Dimensions shown below include the 3mm)
200
417
417
MODEL A
DS1150 1073
DS1150 1365
DS1650 1659
If the wall lining used protrudes past the top trim, non-combusble material MUST be used (see image below,
dashed line represents edge of trim).
Combustibles
OK
Non-Combustibles
needed
Combustibles
OK
Non-Combustibles
needed
NOTE: The wall lining directly above the appliance will get warm and hence may discolour paint nishes
that are suscepble to temperature damage. The heat may also distort vinyl wall coverings. For durability
of nishes and surfaces you should contact the relevant manufacturer for their specicaon and avoid
materials with temperature rangs not suitable for use above a replace.
The wall lining can be xed to the wall lining xing bracket (shaded below). There are mulple areas on the
bracket (circled below) that can be used for xing screws.
