ESI 900 - Function 7124: PRI diagnostics report

IP Server 900 Programming Manual Function 7: Reports
J.5
Function 7124: PRI diagnostics report
Provides a log of errors and parameter settings for each PRI span in the system.
To print a PRI diagnostic report, press 1 and press # to confirm.
PRI DIAGNOSTICS
PRESS 1
Here is a sample of output from a Function 7124 PRI diagnostics report:
============ PRI Diagnostics Report ============ 10/11/2010 13:07
++++++++++++++++++++++ PRI Card slot: 4 ++++++++++++++++++++++++
-------------------------- Parameters --------------------------
PLL:4 Protocol: National N12 LBO:0 Tone:0
PLL status: Enabled - Master TS:8 Echo:FF55 - Add
--------- Slip count ---------
Cur:53399 Last:53688 Rate:18
------------------------ Status monitor ------------------------
Valid intervals: 450 Current interval: 455
Current interval seconds: 510 Current status: 0
-------------- Current 15 minute interval errors ---------------
bursty severe contrld.
Errored unavail. errored errored slip loss of
seconds seconds seconds seconds seconds frame
------- -------- ------- ------- ------- -------
0 0 0 0 0 0
ESP
errors
-------------- Errors in past 24-hour period ------------ ------
4 2 0 0 2 0 0
++++++++++++++++++++++ PRI Card slot: 11 +++++++++++++++++++++++
-------------------------- Parameters --------------------------
PLL:4 Protocol: National N12 LBO:0 Tone:0
PLL status: Enabled - Master TS:8 Echo:FF55 - Add
--------- Slip count ---------
Cur:53399 Last:53688 Rate:18
------------------------ Status monitor ------------------------
Valid intervals: 600 Current interval: 600
Current interval seconds: 712 Current status: 0
-------------- Current 15 minute interval errors ---------------
bursty severe contrld.
Errored unavail. errored errored slip loss of
seconds seconds seconds seconds seconds frame
------- -------- ------- ------- ------- -------
0 0 0 0 0 0
ESP
errors
-------------- Errors in past 24-hour period ------------ ------
4 2 0 0 2 0 0
Information in PRI diagnostics report
• Slips (controlled slips)
— Caused by timing problems
— Links with multiple telcos are highly susceptible to slips
• BPV (bi-polar violations)
— Equipment is set to AMI instead of B8ZS (or vice versa)
— Noise
— With slips could be caused by NEXT (near-end crosstalk)
