IP Server 900 Programming Manual Function 1: System function programming
D.14
Function 18: SMDR settings
Real-time SMDR call records are continuously output to the IP Server 900’s Ethernet port.
Note: Choose STORED in step 1 to have SMDR activity recorded to the ASC’s Memory Module.
Once STORED is selected, the second option (SMDR format) will no longer appear.
1. Select the output device by pressing the scroll keys ( and ):
• NONE (Making this selection ends the process at this step.)
• STORED.
• ETHERNET (if connecting to a LAN through an NSP board).
2. Select the SMDR format, STANDARD, EXTENDED, or CSV, by pressing the scroll keys ( and ).
Default: STANDARD.
Note: If STORED was selected in step 1, the SMDR format will be extended and no output will be seen.
Capturing SMDR data over Ethernet
The NSP can be used to output SMDR data over an IP network; and a Telnet connection can be made to the
NSP, using port xx003 (default is 59003), to capture this data. For more information, see NSP Installation
Made Simple (ESI # 0450-0669).
SMDR output
Examples of SMDR output are shown beginning on page K.1.
