IP Server 900 Programming Manual Function 2: CO line programming
E.13
6. Assign outbound CO line groups
Enter the CO line group (9, 8, or 71–76).
7. Make answer ring assignments
Lines can be programmed with four different ring assignments — Ring 1, Ring 3, Ring 5 and Ring 9.
Each ring count can be programmed for up to 64 extensions, a department, a mailbox, the internal ESI
Fax over e-mail server (ESI FAX), or an auto attendant branch ID.
Notes: Ring assignments don’t apply if DID is enabled in Function 2135.
After you program a ring assignment for a department, mailbox or ID branch, no remaining ring
assignments will be required because, upon reaching any of these, the call is considered answered.
Example:
Ring 1 Ring 3 Ring 5 Ring 9
X100 X100, X101, X102 ID1 Not used
(system won’t
prompt you
to program)
8. Repeat if needed for night programming
Repeat steps 1–7 for night programming.
Function 2132: Line compensation programming
Use the arrow keys to select a value of 1–8 (you can make one selection per installed T1/PRI Module).
Press # to confirm. The level programmed depends on the application (CSU or DSX-1) indicated here:
Level CSU line build-out DSX-1 line build-out
1 0 dB 0 to 133 feet
2 N/A 133 to 266 feet
3 N/A 266 to 399 feet
4 N/A 399 to 533 feet
5 N/A 533 to 655 feet
6 -7.5 dB N/A
7 -15 dB N/A
8 -22.5 dB N/A
Default: 1.
