Chapter 4. API Guides

Once make process is successfully completed, the executable of OpenOCD will be saved in ~/esp/openocd-

esp32/src/openocd directory.

Next Steps To carry on with debugging environment setup, proceed to section Conﬁguring ESP32-S2 Target.

The examples of invoking OpenOCD in this document assume using pre-built binary distribution described in section

Setup of OpenOCD.

To use binaries build locally from sources, change the path to OpenOCD executable to src/openocd and set

the OPENOCD_SCRIPTS environment variable so that OpenOCD can ﬁnd the conﬁguration ﬁles. For Linux and

macOS:

cd ~/esp/openocd-esp32

export OPENOCD_SCRIPTS=$PWD/tcl

For Windows:

cd %USERPROFILE%\esp\openocd-esp32

set "OPENOCD_SCRIPTS=%CD%\tcl"

Example of invoking OpenOCD build locally from sources, for Linux and macOS:

src/openocd -f board/esp32s2-kaluga-1.cfg

and Windows:

src\openocd -f board/esp32s2-kaluga-1.cfg

4.17.9 Tips and Quirks

This section provides collection of links to all tips and quirks referred to from various parts of this guide.

Tips and Quirks

This section provides collection of all tips and quirks referred to from various parts of this guide.

Breakpoints and watchpoints available ESP32-S2 debugger supports 2 hardware implemented breakpoints and

64 software ones. Hardware breakpoints are implemented by ESP32-S2 chip’s logic and can be set anywhere

in the code: either in ﬂash or IRAM program’s regions. Additionally there are 2 types of software break-

points implemented by OpenOCD: ﬂash (up to 32) and IRAM (up to 32) breakpoints. Currently GDB can not

set software breakpoints in ﬂash. So until this limitation is removed those breakpoints have to be emulated by

OpenOCD as hardware ones (see below for details). ESP32-S2 also supports two watchpoints, so two variables can

be watched for change or read by the GDB command watch myVariable. Note that menuconﬁg option CON-

FIG_FREERTOS_WATCHPOINT_END_OF_STACK uses the 2nd watchpoint and will not provide expected results,

if you also try to use it within OpenOCD / GDB. See menuconﬁg’s help for detailed description.

What else should I know about breakpoints? Emulating part of hardware breakpoints using software ﬂash ones

means that the GDB command hb myFunction which is invoked for function in ﬂash will use pure hardware

breakpoint if it is avalable otherwise one of the 32 software ﬂash breakpoints is used. The same rule applies to b

myFunction-like commands. In this case GDB will decide what type of breakpoint to set itself. If myFunction

is resided in writable region (IRAM) software IRAM breakpoint will be used otherwise hardware or software ﬂash

breakpoint is used as it is done for hb command.

Espressif Systems 1382

Submit Document Feedback

Release v4.4
