Espressif ESP32-S2 User Manual

Chapter 4. API Guides
4.12.3 Register Dump and Backtrace
Unless the CONFIG_ESP_SYSTEM_PANIC_SILENT_REBOOT option is enabled, the panic handler prints some
of the CPU registers, and the backtrace, to the console
Core 0 register dump:
PC : 0x400e14ed PS : 0x00060030 A0 : 0x800d0805 A1 :␣
,→0x3ffb5030
A2 : 0x00000000 A3 : 0x00000001 A4 : 0x00000001 A5 :␣
,→0x3ffb50dc
A6 : 0x00000000 A7 : 0x00000001 A8 : 0x00000000 A9 :␣
,→0x3ffb5000
A10 : 0x00000000 A11 : 0x3ffb2bac A12 : 0x40082d1c A13 :␣
,→0x06ff1ff8
A14 : 0x3ffb7078 A15 : 0x00000000 SAR : 0x00000014 EXCCAUSE:␣
,→0x0000001d
EXCVADDR: 0x00000000 LBEG : 0x4000c46c LEND : 0x4000c477 LCOUNT :␣
,→0xffffffff
Backtrace: 0x400e14ed:0x3ffb5030 0x400d0802:0x3ffb5050
The register values printed are the register values in the exception frame, i.e., values at the moment when the CPU
exception or another fatal error has occurred.
A Register dump is not printed if the panic handler has been executed as a result of an abort() call.
In some cases, such as interrupt watchdog timeout, the panic handler may print additional CPU registers (EPC1-
EPC4) and the registers/backtrace of the code running on the other CPU.
The backtrace line contains PC:SP pairs, where PC is the Program Counter and SP is Stack Pointer, for each stack
frame of the current task. If a fatal error happens inside an ISR, the backtrace may include PC:SP pairs both from
the task which was interrupted, and from the ISR.
If IDF Monitor is used, Program Counter values will be converted to code locations (function name, file name, and
line number), and the output will be annotated with additional lines:
Core 0 register dump:
PC : 0x400e14ed PS : 0x00060030 A0 : 0x800d0805 A1 :␣
,→0x3ffb5030
0x400e14ed: app_main at /Users/user/esp/example/main/main.cpp:36
A2 : 0x00000000 A3 : 0x00000001 A4 : 0x00000001 A5 :␣
,→0x3ffb50dc
A6 : 0x00000000 A7 : 0x00000001 A8 : 0x00000000 A9 :␣
,→0x3ffb5000
A10 : 0x00000000 A11 : 0x3ffb2bac A12 : 0x40082d1c A13 :␣
,→0x06ff1ff8
0x40082d1c: _calloc_r at /Users/user/esp/esp-idf/components/newlib/syscalls.c:51
A14 : 0x3ffb7078 A15 : 0x00000000 SAR : 0x00000014 EXCCAUSE:␣
,→0x0000001d
EXCVADDR: 0x00000000 LBEG : 0x4000c46c LEND : 0x4000c477 LCOUNT :␣
,→0xffffffff
Backtrace: 0x400e14ed:0x3ffb5030 0x400d0802:0x3ffb5050
0x400e14ed: app_main at /Users/user/esp/example/main/main.cpp:36
0x400d0802: main_task at /Users/user/esp/esp-idf/components/esp32s2/cpu_start.c:470
To find the location where a fatal error has happened, look at the lines which follow the “Backtrace”line. Fatal
error location is the top line, and subsequent lines show the call stack.
