Espressif ESP32-S2 User Manual

Chapter 4. API Guides
(continued from previous page)
entity1 (scheme1);
section1 -> target1 KEEP() ALIGN(4, pre, post),
section2 -> target2 SURROUND(sym) ALIGN(4, post) SORT()
Putting it all together, the following mapping fragment, for example,
[mapping:name]
archive: lib1.a
entries:
obj1 (noflash);
rodata -> dram0_data KEEP() SORT() ALIGN(8) SURROUND(my_sym)
generates an output on the linker script:
. = ALIGN(8)
_my_sym_start = ABSOLUTE(.)
KEEP(lib1.a:obj1.*( SORT(.rodata) SORT(.rodata.*) ))
_my_sym_end = ABSOLUTE(.)
Note that ALIGN and SURROUND, as mentioned in the flag descriptions, are order sensitive. Therefore, if for the
same mapping fragment these two are switched, the following is generated instead:
_my_sym_start = ABSOLUTE(.)
. = ALIGN(8)
KEEP(lib1.a:obj1.*( SORT(.rodata) SORT(.rodata.*) ))
_my_sym_end = ABSOLUTE(.)
On Symbol-Granularity Placements Symbol granularity placements is possible due to compiler flags -
ffunction-sections and -ffdata-sections. ESP-IDF compiles with these flags by default. If the user
opts to remove these flags, then the symbol-granularity placements will not work. Furthermore, even with the pres-
ence of these flags, there are still other limitations to keep in mind due to the dependence on the compiler’s emitted
output sections.
For example, with -ffunction-sections, separate sections are emitted for each function; with section names
predictably constructed i.e. .text.{func_name} and .literal.{func_name}. This is not the case for
string literals within the function, as they go to pooled or generated section names.
With -fdata-sections, for global scope data the compiler predictably emits either .data.{var_name},
.rodata.{var_name} or .bss.{var_name}; and so Type I mapping entry works for these. However,
this is not the case for static data declared in function scope, as the generated section name is a result of mangling
the variable name with some other information.
Linker Script Template
The linker script template is the skeleton in which the generated placement rules are put into. It is an otherwise
ordinary linker script, with a specific marker syntax that indicates where the generated placement rules are placed.
To reference the placement rules collected under a target token, the following syntax is used:
mapping[target]
Example:
The example below is an excerpt from a possible linker script template. It defines an output section .iram0.text,
and inside is a marker referencing the target iram0_text.
.iram0.text :
{
/* Code marked as runnning out of IRAM */
(continues on next page)
Espressif Systems 1419
Submit Document Feedback
Release v4.4
