Espressif ESP32-S2 User Manual

Chapter 2. API Reference
• Name of CDC device if it is On
• Serial number
If you want to use own descriptors with extended modification, you can define them during the driver installation
process
Install Driver
To initialize the driver, users should call tinyusb_driver_install(). The driver’s configuration is specified
in a tinyusb_config_t structure that is passed as an argument to tinyusb_driver_install().
Note that the tinyusb_config_t structure can be zero initialized (e.g. tinyusb_config_t
tusb_cfg = { 0 }) or partially (as shown below). For any member that is initialized to 0 or NULL,
the driver will use its default configuration values for that member (see example below)
tinyusb_config_t partial_init = {
.descriptor = NULL; //Uses default descriptor specified in Menuconfig
.string_descriptor = NULL; //Uses default string specified in Menuconfig
.external_phy = false;
}
USB Serial Device (CDC-ACM)
If the CDC option is enabled in Menuconfig, the USB Serial Device could be initialized with
tusb_cdc_acm_init() according to the settings from tinyusb_config_cdcacm_t (see example
below).
tinyusb_config_cdcacm_t amc_cfg = {
.usb_dev = TINYUSB_USBDEV_0,
.cdc_port = TINYUSB_CDC_ACM_0,
.rx_unread_buf_sz = 64,
.callback_rx = NULL,
.callback_rx_wanted_char = NULL,
.callback_line_state_changed = NULL,
.callback_line_coding_changed = NULL
};
tusb_cdc_acm_init(&amc_cfg);
To specify callbacks you can either set the pointer to your tusb_cdcacm_callback_t function in the configu-
ration structure or call tinyusb_cdcacm_register_callback() after initialization.
USB Serial Console The driver allows to redirect all standard application strings (stdin/out/err) to the USB Serial
Device and return them to UART using esp_tusb_init_console()/esp_tusb_deinit_console()
functions.
Application Examples
The table below describes the code examples available in the directory peripherals/usb/.
Code Example Description
peripherals/usb/tusb_console How to set up ESP32-S2 chip to get log output via Serial Device connec-
tion
peripherals/usb/tusb_sample_descriptor How to set up ESP32-S2 chip to work as a Generic USB Device with a
user-defined descriptor
peripherals/usb/tusb_serial_device How to set up ESP32-S2 chip to work as a USB Serial Device
Espressif Systems 482
Submit Document Feedback
Release v4.4
