Chapter 2. API Reference
• ESP_OK on success
• ESP_ERR_NOT_SUPPORTED if the host controller does not support IO interrupts
Parameters
• card: pointer to card information structure previously initialized using sdmmc_card_init
esp_err_t sdmmc_io_wait_int(sdmmc_card_t *card, TickType_t timeout_ticks)
Block until an SDIO interrupt is received
Slave uses D1 line to signal interrupt condition to the host. This function can be used to wait for the interrupt.
Return
• ESP_OK if the interrupt is received
• ESP_ERR_NOT_SUPPORTED if the host controller does not support IO interrupts
• ESP_ERR_TIMEOUT if the interrupt does not happen in timeout_ticks
Parameters
• card: pointer to card information structure previously initialized using sdmmc_card_init
• timeout_ticks: time to wait for the interrupt, in RTOS ticks
esp_err_t sdmmc_io_get_cis_data(sdmmc_card_t *card, uint8_t *out_buffer, size_t buffer_size,
size_t *inout_cis_size)
Get the data of CIS region of an SDIO card.
You may provide a buffer not sufficient to store all the CIS data. In this case, this function stores as much data
into your buffer as possible. Also, this function will try to get and return the size required for you.
Return
• ESP_OK: on success
• ESP_ERR_INVALID_RESPONSE: if the card does not (correctly) support CIS.
• ESP_ERR_INVALID_SIZE: CIS_CODE_END found, but buffer_size is less than required size,
which is stored in the inout_cis_size then.
• ESP_ERR_NOT_FOUND: if the CIS_CODE_END not found. Increase input value of in-
out_cis_size or set it to 0, if you still want to search for the end; output value of inout_cis_size
is invalid in this case.
• and other error code return from sdmmc_io_read_bytes
Parameters
• card: pointer to card information structure previously initialized using sdmmc_card_init
• out_buffer: Output buffer of the CIS data
• buffer_size: Size of the buffer.
• inout_cis_size: Mandatory, pointer to a size, input and output.
– input: Limitation of maximum searching range, should be 0 or larger than buffer_size. The
function searches for CIS_CODE_END until this range. Set to 0 to search infinitely.
– output: The size required to store all the CIS data, if CIS_CODE_END is found.
esp_err_t sdmmc_io_print_cis_info(uint8_t *buffer, size_t buffer_size, FILE *fp)
Parse and print the CIS information of an SDIO card.
Note Not all the CIS codes and all kinds of tuples are supported. If you see some unresolved code, you can
add the parsing of these code in sdmmc_io.c and contribute to the IDF through the Github repository.
using sdmmc_card_init
Return
• ESP_OK: on success
• ESP_ERR_NOT_SUPPORTED: if the value from the card is not supported to be parsed.
• ESP_ERR_INVALID_SIZE: if the CIS size fields are not correct.
Parameters
• buffer: Buffer to parse
• buffer_size: Size of the buffer.
• fp: File pointer to print to, set to NULL to print to stdout.
Header File
• components/driver/include/driver/sdmmc_types.h
Espressif Systems 735
Submit Document Feedback
Release v4.4
